Second Generation Toughbook 40 is here
With the success of the Toughbook 40 which is the 1st Toughbook with 14" display size, Panasonic has release the second generation of the modular Toughbook 40 MK2.
The Toughbook 40 MK2 has 4 expansion slots area: Right, Left, Palm Rest and Rear. The expansion slots would give users options such as additional ports, additional battery, additional HDD or optical drive, card slots, etc. In addition to the expansion slots, the Toughbook 40 also has user-replaceable backlit keyboard, RAM and main HDD option. With this modular systems, user has more flexibility to add additional ports or upgrades post-sales therefore ensuring even better ROI and product longevity than they had before.
The Toughbook 40 is powered by the latest Intel Ultra 5 and Ultra 7 Processors and runs Windows 11 Professional. It comes installed with 6300mAh battery which gives it operating life of up to 12 hours (24 hours if you add the optional 2nd battery - Mobile Mark 25).
The Toughbook 40 MK2 is equipped with 4x microphones providing unparalleled speech recognition accuracy. It also has an integrated top facing 95db speakers which is loud enough to hear from the back of the room. For night or dark environment user there is color-selectable backlit keyboard that can be added.
Toughbook 40 comes with the latest Intel Wi-Fi 7 BE200 + Bluetooth v5.3 (Class 1) providing fast connection to other devices. It also has the fastest cellular in the industry, up to 2Gbps 4G modem or 5.5Gbps 5G modem adds Sub6, C-band and mmWave.
The Toughbook 40 MK2 with its modular system is what we believe all future rugged devices will be, that is to provide stable, rugged and productive device that also protect and increase Return on Investment for its users.
Suitable for use in:
- military
- law enforcement
- emergency services
- mining
- retail / sales
- construction
- service / hospitality
- education
- healthcare
- warehouse
- outdoor field works
- surveying
- manufacturing
- maintenance work
Features
- Magnesium alloy chassis with handle
- User-removable xPAK's, RAM, keyboard, battery and caged SSD
- Raised bezel for LCD impact protection
- Reinforced locking port covers
- Replaceable screen protector
- User-removable buttons/keys
- 6 display mode (auto, rain, glove, touch, pen, pen/touch)
- Display Concealed Mode & Day/Night Mode
- Anti-reflective (AR) screen treatment
- Backlit power button & keyboard icons
- Integrated tetra-array microphone
- Integrated 95db speakers (top facing)
- Integrated with military-grade security and communications capabilities to support Defence operations
- Comes with One touch Concealed Mode function featuring a super reduced brightness screen and keyboard for night use, and disabling of status LED's, speaker volume and communication (4G, WiFi, BT)
- Comes in all black non-reflective chassis to prevent detection
- 82-key Keyboard
- Hot swap with optional 2nd battery
- Stylus pen, stylus holder and cleaning cloth
- TPM v2.0
- Kensington cable lock slot
- MIL-STD-810H and IP66 Certified
Upgrades (Some upgrades are subject to minimum quantity requirements)
- Up to 64GB Max RAM
- Up to 2TB Main Max Storage
- Up to 1TB 2nd Max Storage
- Optional 5G EM9190 with eSIM support
- Optional u-blox NEO-M9N (supports GPS, GLONASS, Beidou, Galileo)
- Optional 2nd battery or Smart Card reader (Right Expansion)
- Optional Blu-Ray Drive or DVD Drive or Smart Card reader or 2nd SSD Storage (Left Expansion)
- Optional VGA + True Serial (RS232) + 2nd native GLAN or USB 3.2 Type A + True Serial (RS232) + 2nd HDMI or USB 3.2 Type A + USB 3.2 Type A + 2nd HDMI or 2nd HDMI + USB 3.2 Type A + 2nd USB 3.2 Type C (Rear Expansion)
- Optional Fingerprint reader (Windows Hello) or Fingerprint reader (Windows Hello, Multi-user authentication) or Contactless Smart Card Reader (HF-RFID) (Palm Rest Expansion)
Specifications
- Windows 11 Professional 64-bit
- Intel Core Ultra5 135H Processor (with Intel vPro Technology)
- 16GB DDR4-3200 SDRAM
- 512GB NVMe OPAL SSD
- 14" Active Matrix (TFT) FHD 1920 x 1080 capacitive touchscreen display with gloved and rain mode; Anti-reflective (AR) screen treatment; Sunlight readable 1200 NITS screen brightness
- Intel Graphics (Built-in CPU) - support Intel Arc Graphics when equipped with 2x RAM modules
- Integrated tetra-array microphone & 95db speakers
- 5MP Webcam with IR and privacy cover (Windows Hello compliant)
- Rubber Backlit Keyboard
- Intel Wi-Fi 7 BE200 + Bluetooth v5.3 (Class 1)
- 4G EM7690 with eSIM support
- Ports: USB-C Thunderbolt 4, USB 3.2 Type-A x 2, HDMI, LAN RJ45, Audio, Docking Connector, DC in
- MicroSDXC Reader
- 6300mAh 10.8V Li-Ion Battery (up to 12 hours operating life, up to 24 hours operating life with optional 2nd battery - Mobile Mark 25)
- Dimensions: 35.4 x 30.1 x 5.44 cm
- Weight: 3.35 kg
- 3 Years Warranty
- 1.8m drop resistance
- IP66 & MIL-STD-810H Certified
- Operating Temperature:
- -29 °C to 63 °C
- Operating Humidity:
- 30% to 80% RH (No condensation)
- Storage Humidity:
- 30% to 90% RH (No condensation)
- Operating Altitude:
- Sea level to 15K ft (4572m)
- Drop Shock Rating:
- 180cm
- Certifications:
- IP66 and MIL-STD-810H
